Uniaxial Geogrid
Uniaxial GeogridUniaxial GeogridUniaxial GeogridUniaxial GeogridUniaxial Geogrid

Uniaxial Geogrid


Material:              PP, HDPE

Size:                    General specifications or customized on request

Certificate:           SGS, BV, ISO9001, ISO14001, ISO45001

Brand:                  HG Fencing

Manufacturer:      HUA GUANG

Origin:                  China


Inquire Now
Share:
Uniaxial GeogridUniaxial GeogridUniaxial GeogridUniaxial GeogridUniaxial Geogrid
Specification

Uniaxial Geogrid

Description of Uniaxial Geogrid

Uniaxial Geogrid are made of polymers, which are produced by extrusion, stamping, heating and stretching processes. This structure then has a fairly high tensile strength and tensile modulus, which can effectively improve the bearing capacity of foundations, retaining walls and dams, and is now a widely used reinforcement material.

There are two types, PP Uniaxial Geogrid and HDPE Uniaxial Geogrid.


▶ Enhance the stability and bearing capacity of the roadbed, prevent the deformation of the roadbed, cracking, and prolong the service life.
▶ Easy and fast construction, shorten the construction period, reduce project cost and maintenance cost.
▶ HDPE unidirectional geogrid has low creep deformation characteristics, which can greatly slow down the aging of the grating.
▶ ISO, CE, ASTM, ISO, CRCC certified, product quality is guaranteed.

Specification of Uniaxial Geogrid

PP Uniaxial Geogrid:

Index PropertiesUnitGG60PPGG80PPGG110PPGG1 50PPGG260PPGG300PP
Tensile StengthkN/m6080110150260300
Elongation Ratio≤10
Strength at 2% Elongation≥kN/m1726324594105
Strength at 5% Elongation≥kN/m35486490185195
Roll Lengthm10010050505050
Roll Widthm1-3

Uniaxial Geogrid


HDPE Uniaxial Geogrid:

Index PropertiesTest MethodUnitGG60PEGG80PEGG120PEGG160PEGG180PEGG200PE
Polymer

HDPE
Minimum Carbon BlackASTM D 42182
Tensile Strength @ 2%StrainASTM D 6637kN/m162335475258
Tensile Strength @ 5% StrainASTM D 6637kN/m31446593104116
Ultimate Tensile StrengthASTM D 6637kN/m6080120160180200
Strain @ Ulimate StrengthASTM D 663711.5
Junction fficiencyGRI GG2-87939393939090
Flexural RigidityASTM D 1388mg-cm1,40,0002,300,0006,600,000019,000,000--
UV ResistanceASTM D 435598
Oxidation ResistanceEN ISO 13438100
BrittlenessWashDOT T926-Pass
Minimum Reduction Factor for Installation Damage (RFid)ASTM D5818-1.00
Reduction Factor for Creep for 114-year Design Life (RFcr)ASTM D5262-2.23
Roll Width-m1/2
Roll Length-m1005050505050

Uniaxial Geogrid

Details of Uniaxial Geogrid

●High tensile strength

●High elastic modulus

Uniaxial Geogrid


Production of Uniaxial Geogrid

HG Fencing has 40 sets of advanced production lines for plastic mesh and geogrid, all of which have reached international advanced level.


Uniaxial Geogrid


Application of Biaxial Plastic Geogrid

● Retaining wall reinforcement

● Railroad reinforcement

● Steep Slope Reinforcement

● Dam reinforcement

● Reclamation


Uniaxial Geogrid

Drawing
Packing & Delivery
Uniaxial Geogrid
Uniaxial Geogrid
Uniaxial Geogrid
Uniaxial Geogrid
Project
