Chain Link Temporary Fence
Chain Link Temporary FenceChain Link Temporary FenceChain Link Temporary FenceChain Link Temporary FenceChain Link Temporary Fence

Chain Link Temporary Fence


Material:              Iron steel wires and tubes

Size:                    General specifications or customized on request

Certificate:           SGS, BV, ISO9001, ISO14001, ISO45001

Brand:                  HG Fencing

Manufacturer:      HUA GUANG

Origin:                  China


Inquire Now
Share:
Chain Link Temporary FenceChain Link Temporary FenceChain Link Temporary FenceChain Link Temporary FenceChain Link Temporary Fence
Specification

Chain Link Temporary Fence is made of high strength galvanized steel pipe welded into a frame, filled with flexible Chain Link Mesh inside and the base is welded with steel pipe, Chain Link Temporary Fence is a kind of temporary fence, also known as Chain Link Fence Panel or Construction Fence. It is commonly used to maintain crowd order and prevent stampede events, such as temporary events, concerts, road maintenance, outdoor celebrations, entrance to pavilions, epidemic prevention, etc.


Chain Link Temporary Fences are used for cargo storage

Temporary fencing with chain link mesh features

● Simple construction and light weight. Temporary fences are easy to install, maintain and replace, saving money and labour.
● No need to excavate the road, no need to install the posts, just put the mesh on top of the base and it can be installed.
● Galvanised for good corrosion resistance, the chain link temporary fence can be used both temporarily and permanently.
● With a flat base and saddle clips at the top to secure adjacent mesh, the chain link temporary fence will not wobble.
● The internal chain link fence has good flexibility and can quickly recover its original shape after impact without deformation.

For more information about this product or solution, please contact one of HG fencing's experienced customer service representatives who can provide you with more detailed answers and design a more reasonable solution.

Chain Link Temporary Fence's Technical Parameters

Materialgalvanized steel tube and galvanized Steel wire
Wire diameter1.5mm--4.0mm
Opening Size40*40mm; 50*50mm; 60*60mm; 75*75mm etc.
Height * Length
6'H x 10'L; 8'H x 10'L; 8'H x 12'L etc.
Frame diameterOD25mm; OD32mm; OD48mm
Frame thickness1.5--3.0mm
Base30'' x 18'' or others according your requirement

Chain Link Temporary Fence Details

Chain Link Temporary Fence sample in HG Fencing's factory

Chain Link Temporary Fence tie wire in HG's Fencing CompanyChain Link Temporary Fence Panel Stand


















Chain Link Temporary Fence panels Styles

There are three common styles of chain link temporary fencing.

  • 1. a style with galvanised steel pipe as the surrounding frame, with a vertical brace in the middle, and the chain link fence tied directly to the frame by galvanised wire.

  • 2. a style with galvanized steel pipe as the surrounding frame, then galvanized steel bars through the chain link mesh, and finally with clips to fix the bars on the left and right side of the inner frame. The Temporary fencing panles is more stable and durable.

  • 3. The third style is to use galvanized steel pipe as the surrounding frame, with one horizontal and one vertical brace in the middle, and tie the chain link fence to the frame with galvanized iron wire. This style is suitable for larger size temporary fence panels, which can make the mesh panel more solid and not easy to deform.

Style 1: chain link temporary fence with one vertical brace in the middle and no steel bar.

chain link temporary fence with one vertical brace in the middle and no steel bar.


Style 2: chain link temporary fence with one vertical brace in the middle and steel bars.

Chain Link Temporary Fence


Style 3: chain link temporary fence with one vertical brace and one horizontal brace in the middle and steel bars.


Chain Link Temporary Fence


Chain Link Temporary Fence Panel Feet Base / Panel Stand

type 1: Use four steel tubes welded into a right-angled rectangle. A horizontal tube is welded in the middle and two vertical tubes are welded on it for fixing the temporary fence panels, sandbags can be placed on the top side of the panel stand to enhance the stability of the temporary fence.

Right-angled rectangle Fence feet base / panel standRight-angled rectangle Fence feet base / panel stand with sand bag


















type 2: A steel tube folded into a rectangle with rounded corners and finally welded together, a horizontal tube is welded in the middle and two vertical tubes are welded on it for fixing the temporary fence panels, this kind of welding method, can well protect the inside of the steel tube, the corrosion resistance is very strong, the life is longer, And candbags can be placed on the top side of the panel stand to enhance the stability of the temporary fence.


Rounded corners rectangle Fence feet base / panel standRounded corners rectangle Fence feet base / panel stand with sand bag
















Chain Link Temporary Fence Accessories

Each set of Chain Link temporary fence will come with a set of clips, which are used to fix two adjacent pieces of mesh during installation. This allows the temporary fence to be more stable and able to withstand stronger impacts.


Chain Link Temporary Fence ClipChain Link Temporary Fence clip
















Chain Link Temporary Fence Production Process

1. High-strength steel tubes are selected as the raw material, then cut and welded to form the frame.

2. The welded frame is then hot-dip galvanised and sprayed with anti-rust paint to increase its corrosion resistance.

3. The high quality hot-dip galvanised wire is then fully automatic weaved to form the chain link mesh.

4. The chain link mesh is fastened to the frame by means of wire ties or by passing the chain link mesh through an iron bar and fixing the bar to the frame.

Chain Link Temporary Fence Prodcution Process

Chain Link Temporary Fence Uses

- For construction site fencing

- Residential sites and schools

- Large public events, sporting events, outdoor festivals, assemblies, sports grounds or swimming pools.

- Road traffic control and crowd control.



Drawing
Packing & Delivery
Chain Link Temporary Fence
Chain Link Temporary Fence
Chain Link Temporary Fence
Chain Link Temporary Fence
Project
Chain Link Temporary Fence Panels
Chain Link Temporary Fence Panels
Chain Link Temporary Fence Panels
Chain Link Temporary Fence Panels
