Material: PP, PE
Size: General specifications or customized on request
Certificate: SGS, BV, ISO9001, ISO14001, ISO45001
Brand: HG Fencing
Manufacturer: HUA GUANG
Origin: China
Geogrids are geosynthetics with large openings or apertures. Geogrids are used as soil reinforcement under roads, under structures, and behind retaining walls.
Biaxial plastic geogrids are made of polymeric polypropylene that is extruded into sheets, then beaten into a regular mesh pattern, and finally stretched in both the longitudinal and transverse directions.
The material of biaxial geogrids has a high tensile strength in both the longitudinal and transverse directions, and this bi-directional structure provides an ideal interlocking system for more effective load-bearing in the soil. It is suitable for reinforcing foundations that are permanently loaded over large areas.
▶ Enhance the bearing capacity of the foundation, prevent cracks and collapse of the road surface, and extend the service life of the foundation.
▶ Enhance the stability of soil slope and prevent soil erosion.
▶ Easy construction, cheap price, save construction time and reduce maintenance cost.
▶ Bidirectional Geogrid Better performance than Unixial Geogrid.
| Spec Item | TGSG15-15 | TGSG20-20 | TGSG30-30 | TGSG40-40 | TGSG50-50 |
| Width | 1m - 6m | ||||
| Longitudinal Tensile Strength ≥(KN/m) | 15 | 20 | 30 | 40 | 50 |
| Transverse Tensile Strength≥(KN/m) | 15 | 20 | 30 | 40 | 50 |
| Longitudinal Elongation≤(%) | 16 | ||||
| Transverse Elongation≤(%) | 13 | ||||
| Longitudinal Strength at 2% Strain ≥(KN/m) | 5 | 8 | 11 | 13 | 17 |
| Transverse Strength at 2% Strain ≥(KN/m) | 7 | 10 | 13 | 15 | 20 |
| Longitudinal Strength at 5% Strain ≥(KN/m) | 8 | 10 | 15 | 16 | 35 |
| Transverse Strength at 5% Strain ≥(KN/m) | 10 | 13 | 15 | 20 | 31 |
